Gulf-Tek Generators – Heat Exchange Cooled
Heat Exchange Cooled Generators
Ready to work in harsh marine applications.
This industrial marine generator set is assembled with the highest quality accessories to meet harsh saltwater applications.
- Kubota diesel engines, freshwater heat exchanger with mounted raw water pump, air cleaner, fuel filter, SS water and exhaust discharge elbow
- Marathon or Newage 1800 rpm generator
- High temp and low oil shutdown, hour meter, key switch
- Structural steel all welded epoxy coated skid and stableflex vibration isolators.
| Model | KG5KWHEC | KG8KWHEC | KG10KWHEC | KG12KWHEC |
|---|---|---|---|---|
| Engine | 7.9 hp @1800 rpm | 10 hp @ 1800 rpm | 13 hp @1800 rpm | 17 hp @1800 rpm |
| Generator | 5KW dedicated single phase (3 phase optional) | 8KW dedicated single phase (3 phase optional) | 10KW dedicated single phase (3 phase optional) | 12KW dedicated single phase (3 phase optional) |
| Skid | Structural steel skid, neoprene vibration isolators | Structural steel skid, neoprene vibration isolators | Structural steel skid, neoprene vibration isolators | Structural steel skid, neoprene vibration isolators |
| Warranty | 2-year engine major components, 1-year generator | 2-year engine major components, 1-year generator | 2-year engine major components, 1-year generator | 2-year engine major components, 1-year generator |
| Download Spec Sheet |
| Model | KG15KWHEC | KG17KWHEC | KG20KWHEC | KG30KWHEC |
|---|---|---|---|---|
| Engine | 20 hp @1800 rpm | 24 hp @1800 rpm | 26 hp @1800 rpm | 42 hp @1800 rpm |
| Generator | 15KW dedicated single phase (3 phase optional) | 17KW dedicated single phase (3 phase optional) | 20KW dedicated single phase (3 phase optional) | 20KW dedicated single phase (3 phase optional) |
| Skid | Structural steel skid, neoprene vibration isolators | Structural steel skid, neoprene vibration isolators | Structural steel skid, neoprene vibration isolators | Structural steel skid, neoprene vibration isolators |
| Warranty | 2-year engine major components, 1-year generator | 2-year engine major components, 1-year generator | 2-year engine major components, 1-year generator | 2-year engine major components, 1-year generator |
| Download Spec Sheet |
