Heavy-Duty Diesel Pumps
Gulf-Tek Diesel Pumps – Heavy Duty Series
Built to handle harsh oilfield duty.
Equipped with the number-one-rated diesel engine in the rental industry, these Kubota engine and AMT pump combos are matched to deliver efficient high flow and solids capability. The pump set and skid design meet oilfield industry standards (the pump end is not designed to handle drilling fluids).
- Kubota air/oil cooled diesel engines
- Electric start (recoil optional)
- Aluminum pumps with cast-iron volute and impeller
- Units are roll framed mounted in painted frames with vibration isolators
- Camlock suction and discharge fittings are standard
Heavy-Duty Diesel Pump Models
| Model | DPH2X2CAMT | DPH3X3CAMT | DPH2X2TAMT | DPH3X3TAMT | DPH4X4TAMT |
|---|---|---|---|---|---|
| Engine | Kubota OC60 (tier 3 certified) 6.0hp air/oil cooled diesel engine, electric start with recoil start back up, mounted key switch and wiring harness, 12 volt battery with box and cables | Kubota OC60 (tier 3 certified) 6.0hp air/oil cooled diesel engine, electric start with recoil start back up, mounted key switch and wiring harness, 12 volt battery with box and cables | Kubota OC60 (tier 3 certified) 6.0hp air/oil cooled diesel engine, electric start with recoil start back up, mounted key switch and wiring harness, 12 volt battery with box and cables | Kubota OC60 (tier 3 certified) 6.0hp air/oil cooled diesel engine, electric start with recoil start back up, mounted key switch and wiring harness, 12 volt battery with box and cables | Kubota OC95 (tier 3 certified) 9.5hp air/oil cooled diesel engine, electric Start with recoil start backup, mounted key switch and wiring harness, 12 volt battery with box and cables |
| Pump | AMT 2X2 centrifugal pump, cast aluminum housing, cast iron volute, impeller and wear plate, silicone carbide mechanical seal, Buna o-rings and check valve, maximum flow 180 gpm, 25 ft. vertical suction lift, suction and discharge camlocks | AMT 3X3 centrifugal pump, cast aluminum housing, cast iron volute, impeller and wear plate, silicone carbide mechanical seal, Buna o-rings and check valve, maximum flow 300 gpm, 25 ft. vertical suction lift, suction and discharge camlocks | AMT 2X2 trash pump, cast aluminum housing, cast iron volute, impeller and wear plate, silicone carbide mechanical seal, Buna o-rings and check valve, maximum flow 180 gpm, 25 ft. vertical suction lift, ¾” solids handling, EZ impeller clean out, suction and discharge camlocks | AMT 3X3 trash pump, cast aluminum housing, cast iron volute, impeller and wear plate, silicone carbide mechanical seal, Buna o-rings and check valve, maximum flow 300 gpm, 25 ft. vertical suction lift, ¾” solids handling, EZ impeller clean out, suction and discharge camlocks | AMT 4X4 trash pump, cast aluminum housing, cast iron volute, impeller and wear plate, silicone carbide mechanical seal, Buna o-rings and check valve, maximum flow 525 gpm, 25 ft. vertical suction lift, 1” solids handling, EZ impeller clean out, suction and discharge camlocks |
| Skid | Structural steel all welded and galvanized roll frame (lifetime warranty), center point lift eye, vibration isolators | Structural steel all welded and galvanized roll frame (lifetime warranty), center point lift eye, vibration isolators | Structural steel all welded and galvanized roll frame (lifetime warranty), center point lift eye, vibration isolators | Structural steel all welded and galvanized roll frame (lifetime warranty), center point lift eye, vibration isolators | Structural steel all welded and galvanized roll frame (lifetime warranty), center point lift eye, vibration isolators |
| Warranty | 2 year engine (major components) 1 year all other, 1 year pump | 2 year engine (major components) 1 year all other, 1 year pump | 2 year engine (major components) 1 year all other, 1 year pump | 2 year engine (major components) 1 year all other, 1 year pump | 2 year engine (major components) 1 year all other, 1 year pump |
| Dimensions (Approximate) | L 33” x W 28” x H 24” | L 33” x W 28” x H 24” | L 33” x W 28” x H 24” | L 33” x W 28” x H 24” | L 37” x W 29” x H 26” |
| Weight | 185 pounds | 185 pounds | 185 pounds | 185 pounds | 360 pounds |
| Options | Spark arrestor, manual air intake shutdown, drip pan, wheel kit with 12” pneumatic tires, custom epoxy paint | Spark arrestor, manual air intake shutdown, drip pan, wheel kit with 12” pneumatic tires, custom epoxy paint | Spark arrestor, manual air intake shutdown, drip pan, wheel kit with 12” pneumatic tires, custom epoxy paint | Spark arrestor, manual air intake shutdown, drip pan, wheel kit with 12” pneumatic tires, custom epoxy paint | Spark arrestor, manual air intake shutdown, drip pan, wheel kit with 12” pneumatic tires, custom epoxy paint |
| Download Spec Sheet |
